Project · 2025 · client not named
Reading batch codes on a bottling line
- What was needed
- A small drinks producer prints a batch code and date on each bottle. Codes were checked by eye on a handful of bottles per run. A smudged printer head once put an unreadable code on most of a pallet, found weeks later.
- What I built
- A camera and light above the conveyor. The software reads the code on every bottle, logs it, and lights a lamp when a code cannot be read.
- What changed
- Every bottle is now checked instead of a sample, and a bad printer head is caught within a few bottles rather than a few weeks. Codes go straight into the spreadsheet they already keep.
- How long it took
- Three weeks, one of them spent on lighting.
The story
I expected the hard part to be the reading. It was the lighting.
Bottles come off the filler wet, and the ceiling lights were reflecting straight into the lens, so the code sat in a white blur. A cheap bracket, an angled light and a matte shield fixed what no amount of software would have.
The reading itself is easier than it sounds, because the code is always printed in the same font in roughly the same place. The system is not trying to read anything in the world — only this printer, on this glass.
What took the remaining time was deciding what should happen when a code cannot be read. Stopping the line was too aggressive for a run of a few thousand bottles. We settled on a lamp and a logged photograph, so the operator can decide.
For the technically minded
Industrial camera with a hardware trigger off the existing bottle sensor, fixed focus, and a diffused bar light at about 30 degrees. Text detection is constrained to a fixed region of interest, then character recognition on a model fine-tuned on around 900 photographs of this printer's output, including deliberately smudged runs. Roughly 40 bottles a minute, well inside what the hardware handles.
Read rate settled around 99.4% on clean print. Anything below the confidence threshold is treated as unreadable rather than guessed — a wrong code logged as correct would be worse than no code at all.
